Part#:HJL36045C

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HJL36045C is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HJL sub-range, featuring a PowerPact H-Frame 150 TMD design. It is a 3-pole (3P) device with a rated current of 45A and offers thermal protection (overload) and magnetic protection (short-circuit). This MCCB has a rated insulation voltage (Ui) of 750 V, a rated voltage (AC) of 600Vac 600Y/347Vac, and a rated voltage (DC) of 250Vdc. It supports a mounting mode of individual unit mount on plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. The degree of protection is IP40, and it operates via a toggle (manual) mechanism. Protection settings include over-current fixed at 45A, short-circuit hold current fixed at 400A, and short-circuit trip current fixed at 850A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 45 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies with voltage, up to 100kA at 240Vac according to UL489 standards. The trip unit type is thermal-magnetic (fixed), without a display, and it has a utilisation category of A. Connection is facilitated by lugs on both load and line sides.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Height
    6.4 in (162.56 mm)
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Continuous Current Rating
    100 %
  • Width
    4.12 in (104.65 mm)
  • Depth
    4.36 in (110.74 mm)
  • Product Or Component Type
    Circuit breaker
  • Line Rated Current
    45 A
  • Mounting Mode
    Unit mount
  • Number Of Poles
    3P
  • Range Of Product
    PowerPact H
  • Magnetic Tripping Current
    850 A
  • Breaking Capacity Code
    J
  • Magnetic Hold Current
    400 A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HJL36045C on Powermatic Associates is $2,339.00. Order now.
