Part#:JGL26000S25

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric JGL26000S25 is a front-operated toggle moulded case non-fusible automatic switch-disconnector designed with a PowerPact J-Frame 250 TMD 2P 250A 600Vac 18kA with lugs on both load and line sides. This 2-pole (2P) switch-disconnector has a rated current of 250A, a rated insulation voltage (Ui) of 750 V, and a rated voltage (AC) of 600Vac 600Y/347Vac. It is designed for individual unit mount on plate, featuring a net height of 235 mm, a net width of 115 mm, and a net depth of 128 mm. The degree of protection provided is IP40, with an operating mode of toggle (manual). The rated operating voltage (Ue) is 600 V, and the rated impulse voltage (Uimp) is 8 kV. The trip current rating and frame current rating are both 250 AT and 250 AF, respectively. It has a short circuit breaking rating of 65kA at 240Vac, 35kA at 480Vac and 480Y/277Vac, 18kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc and 500Vdc, all according to UL489. The utilisation category is A.

Product Details

  • Line Rated Current
    250 A
  • Depth
    5 in (127.00 mm)
  • [Ue] Rated Operational Voltage
    600 V AC
  • Breaking Capacity Code
    G
  • Mounting Mode
    Unit mount
  • Terminal Identifier
    AL250JD
  • Circuit Breaker Type
    J-frame
  • Poles Description
    2P
  • AWG Gauge
    AWG 3/0...350 kcmil aluminium/copper)
  • Height
    7.52 in (191.01 mm)
  • Width
    2.74 in (69.60 mm)
  • Product Or Component Type
    Automatic switch
  • Trip Unit Technology
    Magnetic
  • Range Of Product
    PowerPact J
  • Tightening Torque
    230.12 lbf.in (26 N.m) 0.15…0.29 in² (95…185 mm²) (AWG 3/0...350 kcmil)
  • Magnetic Tripping Current
    3125 A
  • Electrical Connection
    Lugs line Lugs load
  • Short-Circuit Withstand
    65 kA 240 V UL 489 35 kA 480 V UL 489 18 kA 600 V UL 489

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
