Part#:JGL26250

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric JGL26250 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT JGL sub-range, featuring a PowerPact J-Frame 250 TMD 2P 250A design for 600Vac and 18kA with lugs at 80% rated on both load and line sides. It is a 2-pole (2P) device offering thermal protection for overload and magnetic protection for short-circuit scenarios. The rated current is 250A, with a rated insulation voltage (Ui) of 750 V and a rated voltage (AC) of 600Vac 600Y/347Vac. This unit is designed for individual unit mount on plate, with a net height of 191 mm, a net width of 105 mm, and a net depth of 127 mm. It operates with a toggle (manual) mode, has a degree of protection of IP40, and features over-current protection fixed at 250A and short-circuit pickup current adjustable between 1250A and 2500A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 250 AT, and the frame current rating is 250 AF. Its short circuit breaking rating includes 65kA at 240Vac, 35kA at 480Vac, 35kA at 480Y/277Vac, 18kA at 600Vac, 18kA at 600Y/347Vac, 20kA at 250Vdc, and 20kA at 500Vdc, all per UL489 standards. The trip unit type is thermal-magnetic (adjustable) without a display, and it falls under utilisation category A.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Depth
    5 in (127.00 mm)
  • Continuous Current Rating
    80 %
  • Breaking Capacity Code
    G
  • Magnetic Tripping Current
    2500 A
  • Magnetic Hold Current
    1250 A
  • Tightening Torque
    230.12 lbf.in (26 N.m) 0.15…0.29 in² (95…185 mm²) (AWG 3/0...350 kcmil)
  • Product Or Component Type
    Circuit breaker
  • Width
    4.12 in (104.65 mm)
  • Height
    7.52 in (191.01 mm)
  • Number Of Poles
    2P

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of JGL26250 on Powermatic Associates is $4,251.00. Order now.
