M9F53115 Schneider Electric Industrial Automation Components

Product Details

• Curve Code
  D
• [Ui] Rated Insulation Voltage
  500 V AC EN/IEC 60947-2
• Depth
  2.83 in (72 mm)
• Width
  0.71 in (18 mm)
• Poles Description
  1P
• [Uimp] Rated Impulse Withstand Voltage
  6 kVEN/IEC 60947-2
• Range
  Multi 9
• Local Signalling
  ON/OFF indication
• Electrical Durability
  10000 cycles
• Line Rated Current
  15 A 77 °F (25 °C) EN/IEC 60947-2
• Contact Position Indicator
  Yes
• Product Or Component Type
  Miniature circuit-breaker
• Trip Unit Technology
  Thermal-magnetic
• Device Application
  Distribution
• 9 Mm Pitches
  2
• Connections - Terminals
  Ring terminal top or bottom)
• Device Short Name
  C60BPR
• Suitability For Isolation
  Yes EN/IEC 60947-2
• Control Type
  Toggle
• Mechanical Durability
  20000 cycles
Product Name
Multi 9 C60
Number Of Protected Poles
1
Mounting Support
DIN rail
Height
5.00 in (127 mm)
Tightening Torque
17.70 lbf.in (2 N.m) top or bottom
Mounting Mode
Clip-on
Earth-Leakage Protection
Without
Provision For Padlocking
Padlockable
Color
Gray
Magnetic Tripping Limit
12 x In +/- 20 % AC 17 x In +/- 20 % DC
Network Type
AC DC
[Ue] Rated Operational Voltage
240 V AC 50/60 Hz 415 V AC 50/60 Hz 60 V DC
Product Certifications
IEC CCC CSA UL
Standards
EN/IEC 60947-2 GB 14048.2 UL 489 CSA C22.2 No 5
[Ics] Rated Service Breaking Capacity
2.25 kA 75 % EN/IEC 60947-2 - 415 V AC 7.5 kA 75 % EN/IEC 60947-2 - 240 V AC 2.25 kA 75 % GB 14048.2 - 415 V AC 7.5 kA 75 % GB 14048.2 - 240 V AC 15 kA 75 % GB 14048.2 - 60 V DC 15 kA 75 % EN/IEC 60947-2 - 60 V DC
Breaking Capacity
3 kA Icu 415 V AC EN/IEC 60947-2 10 kA Icu 240 V AC EN/IEC 60947-2 20 kA Icu 60 V DC EN/IEC 60947-2 3 kA Icu 415 V AC GB 14048.2 10 kA Icu 240 V AC GB 14048.2 20 kA Icu 60 V DC GB 14048.2 10 kA AIR 277 V AC UL 489 14 kA
