PJP36080CU31A Schneider Electric Industrial Automation Components

PJP36080CU31A on Powermatic Associates
Schneider Electric

Part#:PJP36080CU31A

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - PJP36080CU31A

Product Details

  • Breaking Capacity
    100 kA 240 V AC 65 kA 480 V AC 25 kA 600 V AC
  • Certifications
    IEC CSA UL Listed
  • Tightening Torque
    442.54 lbf.in (50 N.m) 0.15…0.37 in² (95…240 mm²) (AWG 3/0...500 kcmil) 8.85…11.51 lbf.in (1.0…1.3 N.m)
  • Electrical Connection
    Lugs line Terminal nut load
  • Depth
    8.05 in (204.47 mm)
  • Width
    8.27 in (210.06 mm)
  • Height
    12.86 in (326.64 mm)
  • Continuous Current Rating
    100 %
  • Circuit Breaker Rating Code
    J
  • Poles Description
    3P
  • Mounting Mode
    Unit mount
  • Mounting Location
    Bolt-on
  • Module Type
    P-Frame
  • Rated Operatioal Voltage
    600 V AC
  • Device Short Name
    A
  • AWG Gauge
    AWG 3/0...500 kcmil aluminium/copper)3
  • Trip Unit Technology
    Electronic, standard, Micrologic 3.0, LI
  • Range
    PowerPact P
  • Rated Current
    800 A
  • Current Sensor Rating Range
    800 A
  • Product Or Component Type
    Circuit breaker

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PJP36080CU31A on Powermatic Associates is $22,868.00. Order now.
