QO3100BNS Schneider Electric Industrial Automation Components

QO3100BNS on Powermatic Associates
Schneider Electric

Part#:QO3100BNS

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QO3100BNS is a load center designed for surface mounting with a rated current of 100A. It features a connection type of lugs and dimensions of H333mm x W149mm (H13.11" x W5.87"), fitting within a compact space with 3-spaces available. This load center is built with a welded sheet steel enclosure and tin-plated copper busbar, ensuring durability and efficient conductivity. It accommodates 3 single pole circuits and offers a short circuit breaking rating of 22kA. The QO3100BNS is also equipped with a NEMA 1 degree of protection, making it suitable for general indoor use.

Product Details

  • Wiring Configuration
    3-wire
  • Rated Current
    100 A
  • Cover Type
    Surface cover
  • Box Number
    13
  • Number Of Spaces
    3
  • Busbar Material
    Tin plated copper busbar
  • Number Of Phases
    3 phase
  • Enclosure Material
    Welded sheet steel
  • Product Type
    Enclosure
  • Electrical Connection
    Lugs
  • Ground Bar
    Grounding bar (ordered separately)
  • Marketing Trade Name
    QO
  • Surface Finish
    Baked enamel Gray
  • Max Short Circuit Current Rating
    22 kA
  • Width
    5.87 in (149 mm)
  • Enclosure Type
    Enclosure
  • Height
    13.11 in (333 mm)
  • Tightening Torque
    35 lb.in, AWG 14...AWG 10, copper 35 lb.in, AWG 12...AWG 10, aluminium Main lugs 40 lb.in, AWG 8...AWG 4, aluminium/copper Main lugs 50 lb.in, AWG 3...AWG 2, aluminium/copper Main lugs 35 lb.in, AWG 14...AWG 10, copper Main lugs

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QO3100BNS on Powermatic Associates is $149.00. Order now.

QO3100BNS Related Documents

Product Datasheet-1631035712296.pdfInstruction Sheet-1631035712304.pdfCatalog-1631035712300.pdf
