QOU260VH Schneider Electric Industrial Automation Components

QOU260VH on Powermatic Associates
Schneider Electric

Part#:QOU260VH

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOU260VH is a unit-mount Miniature Circuit Breaker (MCB) designed for a rated current of 60A and a rated voltage of 120V to 240V AC. It features slotted box lugs connections for both load and line sides, accommodating a cross-section of 14-2AWG (1 cable Al/Cu). This 2-pole MCB has a short circuit breaking rating of 22kA at 240Vac and 5kA at 48Vdc. The terminals are of the box lugs type, facilitating secure and straightforward installation.

Product Details

  • Electrical Connection
    Slotted box lugs, line side Slotted box lugs, load side
  • Tightening Torque
    45 lbf.in (5.08 N.m) (AWG 14...AWG 2)
  • Depth
    2.95 in (74.93 mm)
  • Mounting Mode
    Unit mount
  • [Ue] Rated Operational Voltage
    120/240 V AC
  • Width
    1.5 in (38.10 mm)
  • Height
    4.05 in (102.87 mm)
  • AWG Gauge
    AWG 14...AWG 2 aluminium/copper
  • Product Or Component Type
    Miniature circuit-breaker
  • Line Rated Current
    60 A
  • Range Of Product
    QOU
  • Circuit Breaker Type
    Standard
  • Circuit Breaker Application
    HACR and Switching Duty rated

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOU260VH on Powermatic Associates is $204.12. Order now.
