TM3DI16K Schneider Electric Industrial Automation Components

Product Details

• Discrete I/O Number
  16
• Product Or Component Type
  Discrete input module
• Current State 1 Guaranteed
  >= 2.5 mA input)
• Discrete Input Current
  5 mA input
• Range Of Product
  Modicon TM3
• Width
  0.84 in (21.4 mm)
• Discrete Input Number
  16 input IEC 61131-2 type 3
• Voltage State 1 Guaranteed
  15...28.8 V input
• Marking
  CE
• Input Impedance
  4.4 kOhm
• Height
  3.54 in (90 mm)
• Discrete Input Voltage
  24 V
• Local Signalling
  for input status 1 LED per channel (green)
• Net Weight
  1.43 lb(US) (0.65 kg)
• Electrical Connection
  HE-10 connector for inputs
• Discrete Input Voltage Type
  DC
• Maximum Cable Distance Between Devices
  Unshielded cable <164.04 ft (50 m) regular input
• Discrete Input Logic
  Sink or source (positive/negative)
• Current State 0 Guaranteed
  <= 1 mA input)
• Depth
  3.20 in (81.3 mm)
Voltage State 0 Guaranteed
0...5 V input
Insulation
Between input and internal logic 500 V AC Non-insulated between inputs
Response Time
4 ms (turn-on) 4 ms (turn-off)
Mounting Support
Top hat type TH35-15 rail IEC 60715 Top hat type TH35-7.5 rail IEC 60715 plate or panel with fixing kit
Current Consumption
5 mA 5 V DC via bus connector at state off) 0 mA 24 V DC via bus connector at state on) 0 mA 24 V DC via bus connector at state off) 35 mA 5 V DC via bus connector at state on)
Range Compatibility
Modicon M241 Modicon M251 Modicon M221 Modicon M262
