BI12-GT30K-AD4X-0.5-RS4.23T/S1732 Turck Inductive Sensors

BI12-GT30K-AD4X-0.5-RS4.23T/S1732 on Powermatic Associates
Turck

Part#:BI12-GT30K-AD4X-0.5-RS4.23T/S1732

Alt. Part#:4417079

Manufacturer:Turck

Category:Inductive Sensors

Product Lifecycle:Active

Product description

BI12-GT30K-AD4X-0.5-RS4.23T/S1732 Turck - BI12-GT30K-AD4X-0.5-RS4.23T/S1732

Product Details

  • Country Of Origin
    USA
  • HTS Code
    8536507000

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of BI12-GT30K-AD4X-0.5-RS4.23T/S1732 on Powermatic Associates is $180.00. Order now.

About the product

Turck BI12-GT30K-AD4X-0.5-RS4.23T/S1732 is a proximity sensor within the BI...-GT30 series, designed as a short barrel silicone tub overtop cable embeddable unit. It operates on a supply voltage range of 10-65Vdc, including nominal values of 12Vdc, 24Vdc, and 48Vdc. The sensor features a PTFE-coated and chrome-plated brass housing for durability, and it connects via a pre-wired 50cm / 20" pigtail cable that terminates with a 4-pin M12 Eurofast QD male connector. Its shape is an M30 fully threaded short cylindrical/barrel, suitable for operation in ambient air temperatures ranging from -40°C to +70°C. This model offers one digital output (10-65Vdc; DC 2-wire) with a sensing distance of 12mm. It includes protection functions against short-circuit (pulsed), overload, and reverse polarity. The thread size is M30, and it operates in a Normally Open (NO) mode.

Manufacturer warranty

BI12-GT30K-AD4X-0.5-RS4.23T/S1732 Turck

$180.00

Your price can be lower.
Log in or Create account to check your discount

Select Qty:

$180.00

$180.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Turck

Powermatic Associates is an authorized Turck distributor, committed to delivering top-tier industrial solutions that align with your operational requirements. Turck is a globally recognized provider of advanced automation technology, specializing in sensor, connectivity, and fieldbus technology. Their extensive product range includes robust sensors such as inductive, capacitive, photoelectric, and...
