LI200P3-Q25LM2-LIU5X3-H1151 Turck Industrial Automation Components

EX-L211-P

Panasonic

Panasonic EX-L211-P is a photo-electric sensor constructed from PBT for the case and glass for the lens, designed to operate within an ambient air temperature range of -10 to +55°C. It has a current consumption of 10mA / 0.01 A and offers a degree of protection rated at IP67. The sensor features a detection spot size of 6mm x 4mm and is capable of detecting objects as small as 2mm with a red light color. It includes a visual position indicator with an orange LED for operation, a green LED for stability, and a green LED for power-ON. The EX-L211-P boasts a response time of 500µs / 0.0005 s and provides 1 x digital output (PNP open-collector / 24Vdc / 50mA). It supports both Light-ON and Dark-ON operating modes and has a sensing distance of 1m. The sensor is equipped with protection functions including outputs short-circuit protection and inverse polarity protection. It features an ultra-compact laser (Class 1) with a built-in amplifier for minute object detection, continuously variable sensitivity adjustment, and is pre-wired with a 2m 4-core 0.15mm2 cabtyre cable with bare end flying leads. The cable includes 4 cores for the receiver and 2 cores for the emitter, with a wavelength of 655 nm.
