NI2-H08-AN7X Turck Industrial Automation Components

Name: NI2-H08-AN7X
Brand: Turck

Part#:NI2-H08-AN7X

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Discontinued

Product description

NI2-H08-AN7X Turck - NI2-H08-AN7X Inductive Sensor

Product Details

Construction size
Ø 8 mm
Mounting
Non-flush
Rated switching distance
2 mm
Output function
NO contact, NPN
Design
Smooth barrel
Ambient temperature
-25…+70 °C
Protection class
IP67
Electrical connection
Cable
Housing material
Metal, 1.4301 (AISI 304)
Operating voltage
10…30 VDC
Cable length (L)
2.0 m

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

About the product

Inductive Sensor, Rated switching distance 2 mm, Cable length (L) 2 m, Non-flush, Smooth barrel, Ø 8 mm, Stainless steel, 1.4301, DC 3-wire, 10…30 VDC, NO contact, NPN output, TTL compatible, Cable connection
