2042-3034 WAGO Industrial Automation Components

2042-3034 on Powermatic Associates
WAGO

Part#:2042-3034

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

2042-3034 WAGO - Relay module; Nominal input voltage: 24 VDC; 1 changeover contact; Limiting continuous current: 10 A; Railway; Green status indicator; Module width: 15 mm

Product Details

  • Weight
    33.10000871 g
  • Country Of Origin
    Germany
  • HTS Code
    85364900990
  • Country of Origin
    Germany
  • Mounting Type
    Pluggable Module For TOPJOB® S Carrier Terminal Block
  • Weight
    33.100 grams
  • Depth
    2.047 inches, 52 millimeters
  • Contact Material
    AgNi
  • Flammability Class
    V0
  • Package Type
    Box
  • Width
    0.61 inches, 15.5 millimeters
  • At Rated Voltage
    250 volts
  • Height
    3.059 inches, 77.7 millimeters

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2042-3034 on Powermatic Associates is $46.53. Order now.

About the product

Wago 2042-3034 is a replacement plug-in relay designed for railway applications with an electromechanical design. It features a rated current of 10A continuous, 6A at 250Vac (AC-15), 2A at 24Vdc (DC-13), and a 30A AC inrush maximum current. The relay is equipped with green LED contacts, a recommended minimum switching load of 12V / 10mA, and a resistance of 1C/O / SPDT (Single Pole Double Throw) contact. It operates within an ambient air temperature range for storage of -40°C to +70°C and has a degree of protection rated at IP20. The net width of the relay is 16.8-30Vdc (24Vdc nom.), with a control voltage range of 0.7...1.25 x Uc for DC and 250Vac max. for AC. It features a control voltage (AC) of 4 kV, a rated active power for single-pole / 1-pole (1P) applications, and silver-nickel (AgNi) contacts. The rated operating voltage (Ue) is designed for 100 000 operations, with a trip current rating of 10 000 000 operations. The dimensions are H77.7mm x W15.5mm x D52mm, indicating a compact design suitable for various applications.
