2061-903 WAGO Industrial Automation Components

WAGO 2061-903 is an SMD PCB terminal block designed for overvoltage category III and pollution degree 2 environments, with a short circuit breaking rating as per IEC/EN 60664-1 standards. It supports a nominal voltage of 250V (III/3), 320V (III/2), and 630V (II/2), with a rated impulse voltage of 4kV across these categories. The rated current for this part is 9A. It features a total of 3 potentials with a 3-pole connection on connection 1. The physical dimensions include a pin spacing of 6mm, a width of 17.7mm, a height of 2.5mm, and a depth of 30mm. It is designed for a maximum of 10 mating cycles and is suitable for use with SMD PCB terminal blocks in the 2061 Series. The terminal block is white, made from Polyamide (PA66) with a flammability class of V0, and uses a copper alloy for the contact material with silver plating. It weighs 0.8g and can operate within a temperature range of -60 to +105°C. The product is RoHS compliant without exemptions, packaged in boxes of 200 pieces, and has a GTIN of 4055143656801. The country of origin is China, with a customs tariff number of 85369010000.
