2110-5304 WAGO Industrial Automation Components

Wago 2110-5304 is a neutral-through terminal block designed for efficient wire connection and distribution. It features push-in CAGE CLAMP spring connections for quick and secure wire installation. This terminal block is rated for currents up to 57A (IEC), 74A (IEC), 65A (UL), 57A (Ex e II), and 50A (Ex e II with jumper). It is designed with a single deck/level, incorporating a lever and button, side and center marking slots, and is suitable for Ex I applications, including a test port. The terminal block has a net height of 8 kV for impulse voltage, with a rated impulse voltage (Uimp) of 10 mm, and a net width indicating a neutral-through pole configuration. It is designed for mounting on DIN-35 rail (35 x 15 / 35 x 7.5) and features a blue and orange actuator. The dimensions are H110.4mm x W10mm x D36.9mm, accommodating wire sizes from 0.5mm2 to 16mm2 or #20AWG to #6AWG, with a 10mm2 nominal cross-section. The terminal block is made from Polyamide (PA) 66, supports 3-wires (1 push-in + 2 push-in) connections, and operates at a voltage rating of 800 V (IEC), 600 V (UL), and 550 V (Ex e II). It is part of the TOPJOB S series.
