232-180 WAGO Industrial Automation Components
Part#:232-180
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
232-180 WAGO - THT female header; straight; Pin spacing 5.08 mm; 20-pole; 0.6 x 1.0 mm solder pin; orange
Product Details
- Weight 17.33000456 g
- Country Of Origin Germany
- HTS Code 85366990990
- Country of Origin Germany
- Width 103.1 millimeters, 4.059 inches
- Depth 0.457 inches, 11.6 millimeters
- Contact Type Tin
- Connection Type For PCB
- Voltage 300 volts, 320 volts
- Contact Material Copper Alloy
- Weight 17.330 grams
- Flammability Class V0
- Insulation Material Polyamide
- Color Orange
- Package Type Box
- Height 0.915 inches, 23.25 millimeters
- Current 12 amperes, 15 amperes
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 232-180 on Powermatic Associates is $14.14. Order now.
About the product
WAGO 232-180 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 320V and 630V under different conditions, and a rated impulse voltage of 4kV. The rated current is 12A according to IEC/EN standards, while UL and CSA ratings vary, with UL 1059 and UL 1977 ratings up to 600V and 15A, and CSA ratings up to 300V and 15A. It features 20 connection points and the same number of potentials, with a single connection type and level. The connector has a pin spacing of 5.08mm, dimensions of 103.1mm in width, 23.25mm in height, and 11.6mm in depth, with a solder pin length of 5mm. It includes variable coding, anti-rotation protection, and is designed for PCB connection with a 90-degree mating direction. The connector is made from orange Polyamide (PA66), with a copper alloy contact material and tin plating. It operates within a temperature range of -60 to +85°C and is RoHS compliant. The product is packaged in boxes of 10 pieces, with a GTIN of 4044918578974, and is manufactured in Germany.
Similar products from: WAGO Industrial Automation Components
Manufacturer warranty
232-180 WAGO
$14.14
Your price can be lower.
Log in or Create account to check your discount
Select Qty:
$14.14
$14.14 each
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 232-180 with other Industrial Automation Components products
Weight
Country Of Origin
HTS Code
Country of Origin
Width
Depth
Contact Type
Connection Type
Voltage
Contact Material
Selected product
232-180
WAGO
232-180 WAGO - THT female header; straight; Pin spacing 5.08 mm; 20-pole; 0.6 x 1.0 mm solder pin; o...
Weight17.33000456 g
Country Of OriginGermany
HTS Code85366990990
Country of OriginGermany
Width103.1 millimeters, 4.059 inc...
Depth0.457 inches, 11.6 millimete...
Contact TypeTin
Connection TypeFor PCB
Voltage300 volts, 320 volts
Contact MaterialCopper Alloy
231-303/107-000
WAGO
231-303/107-000 WAGO - Female plug; 3-pole; screw interlocking flange; 12 AWG max; pin spacing 5.08 ...
