233-402 WAGO Terminal Blocks

WAGO 233-402 is a printed circuit connector with a short circuit breaking rating as per IEC/EN 60664-1. It features nominal voltages of 63V (III/3), 160V (III/2), and 320V (II/2), with rated impulse voltages of 2.5kV for all categories and a rated current of 6A. For UL and CSA standards, it has a rated voltage of 150V and a rated current of 4A for Use Group B. The connector has two connection points, supports a single connection type with one level, and utilizes CAGE CLAMP technology for connection. It accommodates solid and fine-stranded conductors ranging from 0.08 to 0.5mm2 (28 to 20 AWG), with specific notes for terminating 0.75mm2/18 AWG conductors. The strip length for connection is 5 to 6mm, and the conductor connection direction to the PCB is 30 degrees. It has a pin spacing of 2.54mm, dimensions of 7.38mm in width, 15.7mm in height, 12.1mm in depth, and a solder pin length of 4mm. The connector is made from Polyamide (PA66) in orange color, with a flammability class of V0 and uses Chrome-Nickel spring steel for the clamping spring and Electrolytic Copper with tin plating for contacts. It operates within a temperature range of -60 to +105°C, weighs 0.8g, and is RoHS compliant. The product is packaged in boxes with 600 pieces per unit and has a GTIN of 4045454049898.
