235-403/331-000 WAGO Terminal Blocks
Part#:235-403/331-000
Manufacturer:WAGO
Category:Terminal Blocks
Product Lifecycle:Active
Product description
235-403/331-000 WAGO - PCB terminal block; push-button; 1.5 mm²; Pin spacing 5/5.08 mm; 3-pole; Push-in CAGE CLAMP®; 1,50 mm²; gray
Product Details
- Weight 2.400000631 g
- Country Of Origin China
- HTS Code 85369010000
- Actuator Push-button
- Country of Origin China
- Width 0.65 inches, 16.5 millimeters
- Contact Material Copper
- Voltage 250 volts, 300 volts
- Conductor Size 1.5 millimeters, 14 american wire gauge
- Package Type Box
- Contact Type Tin
- Weight 2.400 grams
- Depth 0.492 inches, 12.5 millimeters
- Current 10 amperes, 17.5 amperes
- Height 0.752 inches, 19.1 millimeters
- Color Gray
- Strip Length 0.39 inches, 10 millimeters
- Flammability Class V0
- Insulation Material Polyamide
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 235-403/331-000 on Powermatic Associates is $1.13. Order now.
About the product
WAGO 235-403/331-000 is an automation part with a short circuit breaking rating and electrical data adhering to IEC/EN 60664-1 standards. It features nominal voltages of 250V (III/3), 320V (III/2), and 630V (II/2), with rated impulse voltages of 4kV for all categories and a rated current of 17.5A. UL and CSA approvals include ratings of 300V and 10A for UL (Use Group B and D) and 300V and 15A for CSA (Use Group B). The part has three connection points, supports a single connection type with one level, and utilizes Push-in CAGE CLAMP technology with push-button actuation. It accommodates solid conductors from 0.2 to 1.5mm2 (20 to 14 AWG), fine-stranded conductors from 0.75 to 1.5mm2 (20 to 14 AWG), and both insulated and uninsulated ferrules from 0.25 to 1mm2. The strip length for connections is 9 to 10mm, with a conductor connection direction to PCB of 0° and a pole number of 3. Physically, it has a pin spacing of 5/5.08mm, dimensions of 16.5mm in width, 19.1mm in height, 15.5mm height from the surface, and 12.5mm in depth, with solder pin length of 3.6mm and dimensions of 0.4 x 0.8mm. The drilled hole diameter with tolerance is 1 (+0.1)mm. It features a gray color, made from Polyamide (PA66) with a flammability class of V0, chrome-nickel spring steel (CrNi) for the clamping spring, electrolytic copper (ECu) for contact material, and tin plating. The fire load is 0.046MJ, and it weighs 2.4g. It operates within a temperature range of -60 to +105°C. Packaged in boxes, with 280 pieces per unit (70 pieces per SPU), it is RoHS compliant with no exemptions, has a GTIN of 4055143258630, and a customs tariff number of 85369010000, indicating its country of origin as CN.
