260-158 WAGO Terminal Blocks
Part#:260-158
Manufacturer:WAGO
Category:Terminal Blocks
Product Lifecycle:Active
Product description
260-158 WAGO - 2-conductor terminal strip; without push-buttons; with snap-in mounting feet; 8-pole; for plate thickness 0.6 - 1.2 mm; Fixing hole 3.5 mm Ø; 1.5 mm²; CAGE CLAMP®; 1,50 mm²; gray
Product Details
- Weight 13.75000362 g
- Country Of Origin Germany
- HTS Code 85369010000
- Package Type Box
- Flammability Class V0
- Conductor Material Copper
- Insulation Material Polyamide
- Voltage 400 volts
- Actuator Operating Tool
- Strip Length 0.35 inches, 9 millimeters
- Conductor Size 1.5 millimeters, 16 american wire gauge
- Width 1.709 inches, 43.4 millimeters
- Operating Temperature 105 degrees celsius
- Color Gray
- Depth 0.988 inches, 25.1 millimeters
- Mounting Type Snap-in Foot
- Current 18 amperes
- Country of Origin Germany
- Weight 13.750 grams
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 260-158 on Powermatic Associates is $5.84. Order now.
About the product
Wago 260-158 is a feed-through terminal strip designed for efficient wire connection and distribution. It features CAGE-CLAMP spring connections for secure and maintenance-free wire termination. This terminal strip is rated for an 18A current according to IEC standards and is designed as a 1-deck level with snap-in mounting feet for easy installation. It supports a voltage up to 400V (IEC) and is suitable for both DIN rail and surface mounting through an accessory snap-in foot. The terminal strip accommodates 8 feed-through poles (8P) and is compatible with wire sizes ranging from 0.08mm2 to 1.5mm2 or #28AWG to #16AWG, both fine stranded and solid conductors. The product is made from Polyamide (PA) 66, ensuring durability, and has dimensions of H17.1mm x W43.4mm x D25.1mm. It is designed to connect up to 16 wires across 8 clamps, facilitating organized and efficient wire management.
