2706-103 WAGO Industrial Automation Components

WAGO 2706-103 is an automation part with a short circuit breaking rating and electrical data compliant with IEC/EN 60664-1 standards, featuring nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), with rated impulse voltages of 6kV for all categories and a rated current of 41A. It has UL 1059 approval with rated voltages of 300V and 150V for Use Groups B and C respectively, and a rated current of 30A for all groups. This part offers 3 connection points, a single connection type with CAGE CLAMP technology, lever actuation, and accommodates solid and fine-stranded conductors ranging from 0.5 to 6mm2 (20 to 10 AWG), including those with insulated or uninsulated ferrules. The strip length for connections is 11 to 12mm with a conductor connection direction to PCB at 30 degrees and a pole number of 3. Physically, it has a pin spacing of 7.5mm, dimensions of 22.5mm in width, 30mm in height, 26mm in depth, and a solder pin length of 4.5mm. The PCB contact is THT with an in-line solder pin arrangement. It is made from Polyamide (PA66) in gray, with a flammability class of UL94 V0, and uses Chrome-Nickel spring steel and Electrolytic Copper with tin plating for its contacts. The part operates within a temperature range of -60 to +105°C, weighs 15.6g, and is RoHS compliant without exemptions. It is packaged in boxes of 55 pieces, with a GTIN of 4050821092995 and a customs tariff number of 85369010000, originating from PL.
