286-752/002-000 WAGO Industrial Automation Components

286-752/002-000 on Powermatic Associates
WAGO

Part#:286-752/002-000

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

286-752/002-000 WAGO - Optocoupler module; Red status indicator; gray

Product Details

  • Weight
    18.50000487 g
  • Country Of Origin
    Germany
  • HTS Code
    85365005000
  • Width
    0.591 inches, 15 millimeters
  • Package Type
    Box
  • Depth
    2.047 inches, 52 millimeters
  • Country of Origin
    Germany
  • Weight
    18.500 grams
  • Color
    Gray
  • Mounting Type
    Pluggable Module For Receptacle Terminal Blocks

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 286-752/002-000 on Powermatic Associates is $68.14. Order now.

About the product

Wago 286-752/002-000 is a replacement plug-in solid-state/static relay (SSR) module designed for high-side switching with plug-in connections. It operates with a rated current of 0.5A (continuous) and a rated voltage (DC) of 20Vdc-30Vdc, with a nominal voltage of 24Vdc. The module features a red LED indicator, a 3-wire connection, and is designed for single-pole/single-phase (1P) applications. It does not require a supply voltage (AC), and its control voltage (DC) ranges from 2-6.25Vdc, with a nominal voltage of 5Vdc. The ambient air temperature for operation and storage is specified from -25°C to +70°C. The module has an IP20 degree of protection, a response time for switching ON of 5μs (0.000005 s) and for switching OFF of 10μs (0.00001 s), and supports a 25kHz switching frequency. It is designed to operate within a humidity range of 5-95% relative humidity (RH), with no condensation permissible. The physical dimensions are H82.5mm x W15mm x D52mm.
