289-597 WAGO Industrial Automation Components

WAGO 289-597 is an automation part with an operating voltage of ≤ AC/DC 125V, nominal current of 1A, and a maximum contact resistance of 15mΩ. It features a shield connection for specialty functions. The rated voltage is 125V with a rated surge voltage of 0.8kV and a pollution degree of 2. Its protection type is IP20. The performance level is rated at 3 / 50 mating cycles. Connection 1 includes an HD D-sub male connector with 44 poles, designed for system connection with a conductor cross-section note of 12 AWG THHN; THWN, and a vertical mating direction. Connection 2 features PCB terminal blocks (triple-deck) with 44 poles, field connection type, CAGE CLAMP connection technology, compatible with WAGO 737 Series connectors, and accommodates solid and fine-stranded conductors of 0.08...2.5mm2 / 28...12 AWG with a strip length of 5...6mm / 0.2...0.24". The physical dimensions are 79mm in width, 85mm in height, and a depth from the upper edge of DIN-rail of 62mm. It mounts on a DIN-35 rail within a mounting carrier housing design. The contact material is Au over Ni. The fire load is 1.242MJ, and it weighs 128.9g. It operates in ambient temperatures of -20...+55°C and can be stored in temperatures ranging from -40...+70°C with a relative humidity of ≤ 85% (non-condensing). It meets the EN 61010-2-201 standard. Commercially, it belongs to product group 6 (INTERFACE ELECTRONIC), with eClass 10.0 and 9.0 classifications of 27-14-11-52, ETIM 8.0 and 7.0 classifications of EC002780, packaged in boxes, and has a country of origin of DE with a GTIN of 4045454353551 and a customs tariff number of 85366990990. Environmental product compliance includes a CAS-No. of 7439-92-1, REACH Candidate List Substance of Lead, RoHS Compliance Status of Compliant with Exemption under RoHS Exemption 6(c), and multiple SCIP notification numbers for various EU countries.
