744-392 WAGO Terminal Blocks

WAGO 744-392 is an automation part with a short circuit breaking rating and electrical data adhering to IEC/EN 60664-1 standards. It features nominal voltages of 250V (III/3), 320V (III/2), and 630V (II/2), with rated impulse voltages of 4kV for all categories and a rated current of 3A. According to UL 1059 standards, it has a rated voltage of 300V and a rated current of 6A for both Use Groups B and D. This part offers 2 connection points, supports a single connection type across one level, and utilizes PUSH WIRE technology for connection 1, suitable for solid conductors ranging from 0.5 to 1.5mm2 / 20 to 16 AWG. The physical specifications include a pin spacing of 3.5mm, a width of 7.9mm, a height of 10.1mm, and a depth of 12.5mm, with a solder pin length of 3.5mm. It is designed for THT PCB contact with staggered solder pin arrangement and is made from white Polyamide (PA66) with a V0 flammability class. The clamping spring is made from a copper alloy with tin contact plating. It operates within a temperature range of -60 to +105°C, is RoHS compliant without exemptions, and comes in a box packaging of 1500 pieces per unit. The product's country of origin is CH, and it has a GTIN of 4055143318075 with a customs tariff number of 85369010000.
