789-570 WAGO Industrial Automation Components

Wago 789-570 is a fixed-type relay module featuring CAGE-CLAMP spring connections for secure and maintenance-free connections. It is designed to handle a rated current of 16A continuously, with a maximum inrush current of 50A AC for 20ms. The module includes a red LED indicator and operates on an electromechanical design with bistable/latching functionality. It recommends a minimum switching load of 10V / 10mA. The contact type is 1NO / SPST-NO, suitable for applications requiring a single pole single throw normally open configuration. This relay does not specify a supply voltage for AC but operates within an ambient air temperature range for operation from -25°C to +40°C and for storage from -40°C to +85°C. It has a control voltage categorized under IP20 communication protocol and is designed to withstand a rated impulse voltage (Uimp) of 250Vac max. The relay offers protection functions up to 4kV and is designed for mounting on a DIN-35 rail. Its dimensions are H90mm x W17.5mm x D55mm, with a width of 17.5mm, making it compact for installation. The contacts are made from Silver-Tin (AgSnO) to ensure durability, and it is rated for 50,000 operations digitally, with a hold time of 100,000 operations. The technology used in the component supports a power consumption within 0.85...1.1 x Uc, based on a 195.5-253Vac (230Vac nominal) network.
