.3318OT1BW56-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 115/208-230 V
- Output Rating 0.33 HP
- Rated Speed 1745 rpm
- Flange Type Without
- Frame W56
- Breakdown torque 300 %
- Mounting F-1
- Terminal box¹ Without Terminal Box
- Number of Poles 4
- Starting Method Direct On Line
- Voltage 115/208-230 V
- L. R. Amperes 30.1/16.9-15.0 A
- Design N
- Rotation¹ Both (CW and CCW)
- Approx. weight³ 20.4 lb
- Frequency 60 Hz
- Locked rotor time 30s (cold) 17s (hot)
- Ambient temperature -20°C to +40°C
- Output 0.33 HP (0.25 kW)
- Rated speed 1745 rpm
- Moment of inertia (J) 0.0439 sq.ft.lb
- Duty Cycle Cont.(S1)
- Output rating 0.33 HP
- Slip 3.06 %
- No load current 3.10/1.34-1.55 A
- Insulation Class F
- Synchronous speed 1800 rpm
- Rated current 4.12/2.32-2.06 A
- Enclosure IC01 - ODP
- Flange Without
- Rated voltage 115/208-230 V
- Rated torque 0.993 ft.lb
- Altitude 1000 m.a.s.l.
- Number of poles 4
- Locked rotor torque 320 %
- Temperature rise 80 K
- Noise level² 50.0 dB(A)
- LRC 7.3x(Code M)
- Service factor 1.35 (1.00 @ 208V)
- Standard NEMA MG-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
