00718EP3EPM213/5Y WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 7.5 HP
- Rated Speed 1755 rpm
- Flange Type Without
- L. R. Amperes 122/60.9 A
- Moment of inertia (J) 0.9800 sq.ft.lb
- Service factor 1.25
- Number of poles 4
- Number of Poles 4
- Insulation Class F
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Rated current 19.0/9.52 A
- Breakdown torque 260 %
- Starting Method Direct On Line
- Output rating 7.5 HP
- Rated speed 1755 rpm
- No load current 7.00/3.50 A
- Temperature rise 105 K
- Synchronous speed 1800 rpm
- Material (FERT) 50006910
- Ambient temperature -20°C to +40°C
- Enclosure IC418 - TEAO
- Flange Without
- Output 7.5 HP (5.5 kW)
- Locked rotor torque 200 %
- Altitude 1000 m.a.s.l.
- Standard NEMA MG-1
- Frequency 60 Hz
- Locked rotor time 37s (cold) 21s (hot)
- Duty Cycle Cont.(S1)
- Voltage 230/460 V
- Slip 2.50 %
- Rated torque 22.4 ft.lb
- Degree of Protection IP55
- Rated voltage 230/460 V
- Design B
- Approx. weight³ 137 lb
- Frame 215Y
- LRC 6.4x(Code H)
- Mounting F-1
- Noise level² 58.0 dB(A)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
