10084126 WEG AC Motors
Product Details
- Frequency 60 Hz
- Locked rotor time 27s (cold) 15s (hot)
- Number of poles 4
- Rated speed 1755 rpm
- Temperature rise 80 K
- Degree of Protection IP55
- Rated torque 29.9 ft.lb
- Breakdown torque 250 %
- Mounting F-2
- Design B
- Output 10 HP (7.5 kW)
- LRC 6.3x(Code H)
- Enclosure IC411 - TEFC
- Voltage 230/460//380 V
- Frame 215TC
- Duty Cycle Cont.(S1)
- Standard NEMA MG-1
- Rated current 25.6/12.8 A
- Locked rotor torque 200 %
- Moment of inertia (J) 1.38 sq.ft.lb
- Approx. weight³ 208 lb
- Rated voltage 230/460 V
- Ambient temperature -20°C to +40°C
- Noise level² 58.0 dB(A)
- Slip 2.50 %
- Service factor 1.15
- Rotation¹ Both (CW and CCW)
- Synchronous speed 1800 rpm
- Number of Poles 4
- Starting Method Direct On Line
- Terminal box¹ Right position
- Output rating 10 HP
- L. R. Amperes 161/80.6 A
- No load current 9.60/4.80 A
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Flange C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
