12676265 WEG AC Motors

12676265 on Powermatic Associates

WEG

Part#:12676265

Manufacturer:WEG

Category:AC Motors

Product Lifecycle:Discontinued

Product description

Rolled Steel Standard Efficiency 1 HP 4P 56 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Product Details

L. R. Amperes
10.2 A
Locked rotor time
21s (cold) 12s (hot)
Output rating
1 HP
Standard
NEMA MG-1
LRC
7.7x(Code M)
Locked rotor torque
270 %
Noise level²
52.0 dB(A)
Synchronous speed
1800 rpm
Rated speed
1760 rpm
Service factor
1.15
Rotation¹
Both (CW and CCW)
Rated voltage
575 V
Slip
2.22 %
Duty Cycle
Cont.(S1)
Temperature rise
80 K
Altitude
1000 m.a.s.l.
Terminal box¹
Left position
Number of Poles
4
Breakdown torque
300 %
Degree of Protection
IP55

Flange

Without

Output

1 HP (0.75 kW)

No load current

0.960 A

Design

A

Enclosure

IC411 - TEFC

Voltage

575 V

Rated current

1.33 A

Moment of inertia (J)

0.0842 sq.ft.lb

Mounting

F-1

Number of poles

4

Frequency

60 Hz

Insulation Class

F

Approx. weight³

27.4 lb

Frame

56

Rated torque

2.98 ft.lb

Ambient temperature

-20°C to +40°C

Starting Method

Direct On Line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
