35018ET3G449TS-W22 WEG AC Motors

35018ET3G449TS-W22 on Powermatic Associates

WEG

Part#:35018ET3G449TS-W22

Alt. Part#:7909018469768

Manufacturer:WEG

Category:AC Motors

Product Lifecycle:Active

Product description

W22 NEMA Premium Efficiency 350 HP 4P 447/9TS 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted

Product Details

Number of Poles
4 Pole
Voltage
460 V
Output Rating
350 HP
Rated Speed
1785 rpm
Flange Type
Without
Rated voltage
460 V
Breakdown torque
280 %
Degree of Protection
IP55
Rated torque
1030 ft.lb
Service factor
1.15
Synchronous speed
1800 rpm
Slip
0.83 %
Ambient temperature
-20°C to +40°C
Output rating
350 HP
Number of Poles
4
Locked rotor time
25s (cold) 14s (hot)
No load current
135 A
Design
A
Mounting
F-1
L. R. Amperes
3192 A

Insulation Class

F

Voltage

460 V

Moment of inertia (J)

118 sq.ft.lb

Frame

447/9TS

Frequency

60 Hz

Temperature rise

80 K

Enclosure

IC411 - TEFC

Terminal box¹

Left position

Rated speed

1785 rpm

Rated current

399 A

Altitude

1000 m.a.s.l.

Standard

NEMA MG-1

Duty Cycle

Cont.(S1)

Starting Method

Direct On Line

Approx. weight³

2952 lb

Locked rotor torque

280 %

Flange

Without

Number of poles

4

Noise level²

75.0 dB(A)

Output

350 HP (260 kW)

LRC

8.0x(Code J)

Rotation¹

Both (CW and CCW)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

35018ET3G449TS-W22 Related Documents

Datasheet.pdf Drawings.pdf
