B-TL70-5C Banner Signal Towers

Name: B-TL70-5C
Brand: Banner
Price: 53 USD
Availability: BackOrder

Part#:B-TL70-5C

Alt. Part#:92230

Manufacturer:Banner

Category:Signal Towers

Product Lifecycle:Active

Product description

TL70 Base Module; Supports 1-4 Modules; Voltage: 12-30 V dc; Environmental Rating: IP65; 5 Wire 2 m (6.5 ft) Integral Cable; Gray Housing

Product Details

Weight
226.796 g
Country Of Origin
MX
Pro-Editor Compatible (Discrete)
No
Modbus RTU
No
Wireless
No
IO Link
No
Primary Housing Color
Gray
Feature: Chemical Resistant
No
Storage Temp (°C)
-40 to 70
Feature: Audible
No
Feature: Hazardous Area
No
Min Op. Temperature (°C)
-40
Physical Dimensions (LxWxH or DxH mm)
70.0 x 47.5
Max Op. Temperature (°C)
50
Max Op. Relative Humidity Non-Condensing (%)
95% @ 50°C
Color Technology
Standard LED
Environmental Rating
IP65
Max Input Response Time (ms)
180
Max Current Color (mA)
420
Input Type
Bimodal (PNP/NPN)

Number of Input Pins/Conductors

Number of Colors / Segments

Product Size (mm)

Supply Voltage

12-30 V dc

Connection

Cable

Indication

Yes

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Primary Housing Material

Polycarbonate

Mounting Thread

M30 x 1.5

Power Source

Non-Illuminated

Yes

Housing Style

Segment - Base

Power

Cable Length (m)

0.15

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of B-TL70-5C on Powermatic Associates is $53.00. Order now.

About the product

Banner Engineering B-TL70-5C is a base unit belonging to the Modular series, designed as a base segment/module with a gray polycarbonate housing. It supports 1-4 modules and operates on a supply voltage of 12Vdc-30Vdc, with a nominal voltage of 24Vdc. This unit features a cylindrical shape with a diameter of 70mm / 2-3/4" and is pre-wired with a 2m / 6.5ft 5-core cable terminated with bare end flying leads. It offers a degree of protection rated at IP65 and can be mounted via surface or base pole with an M30 thread. The B-TL70-5C operates within an ambient air temperature range of -40°C to +50°C and includes 4 x digital inputs (12-30Vdc; PNP/NPN) for color control. Its current consumption is rated at 420mA.
