LS2LR30-1500Q8 Banner Safety Light Curtains

LS2LR30-1500Q8 on Powermatic Associates
Banner

Part#:LS2LR30-1500Q8

Alt. Part#:73563

Manufacturer:Banner

Category:Safety Light Curtains

Product Lifecycle:Active

Product description

LS2LR30-1500Q8 EZS TYPE2 R LATCH 30 mm x 1500 mm

Product Details

  • Weight
    2857.6296 g
  • Country Of Origin
    CN
  • Test Input
    Yes
  • Feature: Integral Muting
    No
  • Feature: ESD Safe
    No
  • Feature: End-to-End Sensing
    No
  • Supply Current
    90 mA max.
  • OSSD Rating
    24 V dc at 0.5 A each
  • Housing Material
    Aluminum; Zinc; Acrylic
  • Fault Output
    No
  • Auxiliary Output
    No
  • Vibration
    10-55 Hz at 0.35 mm
  • Trip/Latch Output
    Latch
  • System Type
    Receiver
  • Short Protection
    Yes
  • Shock
    10g at 16ms (6000 cycles)
  • Resolution (mm)
    30
  • Electrical Safety Class
    III
  • SIL Rating
    SIL2; CL2
  • Response Time
    25
  • Reduced Resolution
    No
  • PL Rating
    N/A
  • Scan Code
    None
  • Recovery Time
    N/A
  • Number of Pins (Receiver/Emitter)
    8
  • Operating Temperature
    0 to +55 deg. C; RH 95%
  • Housing Finish
    Yellow Polyester
  • IP Rating
    IP65
  • Fixed Blanking
    No
  • Operating Voltage
    24 V dc +/- 20%
  • Operating Distance (m)
    0.2 - 15
  • External Monitoring Device
    No
  • Dimensions WxD (mm)
    25.4 x 31.8
  • Overall Length (mm)
    1563
  • low-profile
    No
  • Primary Housing Material
    Aluminum
  • Effective Aperture Angle
    Type 2 Per IEC 61496-2
  • Safety Level
    Type 2
  • Defined Area Height (mm)
    1500
  • Connector Type
    M12

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LS2LR30-1500Q8 on Powermatic Associates is $1,963.00. Order now.

About the product

Banner Engineering LS2LR30-1500Q8 is a safety light curtain within the LS2LR series type 2 light screens, designed specifically for hand detection with a resolution of 30mm. This model features a protective height of 1500mm and operates with infrared light at a wavelength of 850 nm. The housing is made of aluminum with an acrylic lens and die-cast zinc end caps, colored yellow. It is equipped with a latch output design and comes pre-equipped with an 8-pin Euro-style M12 connector for connectivity. The LS2LR30-1500Q8 operates on a 24Vdc supply voltage and offers two digital outputs (24Vdc; 500mA; sourcing; redundant OSSD solid-state outputs) with a response time of 25ms. It has a beam spacing/pitch of 30mm and can sense objects within a distance of 20cm to 15m. The device measures 1563mm in height, 26mm in width, and 32mm in depth, ensuring an IP65 degree of protection. It is designed to operate within an ambient air temperature range of 0 to +55°C.
