MQEAC-460 Banner Cordsets
Product Details
- Weight 172.36496 g
- Country Of Origin US
- Maximum Temp. (°C) 80
- Oil/Grease Resistant No
- Current Rating (A) 2.0
- Primary Number of Conductors 4
- Connector Body Material/Color PUR Black
- Primary Gender Female
- Cable Jacket Material PVC
- Voltage Rating (V) 250 V ac/dc
- Cable Jacket Color Yellow
- Primary Coupling Method M12 Dual Key
- Primary AWG 22
- Trunk Length (m) No Trunk
- Shield/No Shield No Shield
- Secondary Connector Type Flying Leads
- Outside Cable Diameter (mm) 5.7
- Primary Connector Type MICRO
- Coupling Material/Color Nickel Plated Brass
- Primary Orientation Straight
- Number of Contacts 4
- Cordset Length (m) 18.3
- IP Rating IP67
- Number of Connectors 1
- Minimum Temp. (°C) -40
- Feature: Hazardous Area No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of MQEAC-460 on Powermatic Associates is $97.00. Order now.
About the product
Banner Engineering MQEAC-460 is a pre-assembled cable/cordset designed for various automation applications. It features a single-ended design with a 4-pin Euro-style M12 male connector and bare end flying leads. The cable has a diameter of 5.7mm and is encased in yellow PVC sheathing. It is 60ft (18m) long and can operate in ambient air temperatures ranging from -40 to +80°C. This model offers a degree of protection of IP67, making it suitable for environments where dust and temporary immersion in water are concerns. The connector's coupling nut is made from nickel-plated brass, ensuring a secure connection. It is rated for a voltage of 250Vac.
