PBT46TSL5-VL Banner Through Beam Sensors

Name: PBT46TSL5-VL
Brand: Banner
Price: 158 USD
Availability: BackOrder

Part#:PBT46TSL5-VL

Alt. Part#:93949

Manufacturer:Banner

Category:Through Beam Sensors

Product Lifecycle:Active

Product description

Plastic Fiber, Diffuse Reflective; Core Dia.: 1 mm; Fiber Length 2 m; Thread M6; Stainless Monocoil; 25 mm Bend Radius; Vantage Line

Product Details

Weight
45.3592 g
Country Of Origin
TW
Fiber Length (m)
2
Feature: Extended Range
No
Max Distance: DF-G1 (mm)
192
Fiber Sensing End Tip
Ferrule
Minimum Bend Radius (mm)
25
Termination Type
Plastic Fiber Sensors
Sensing Mode (Detailed)
Reflective
Retractile
No
Application: Liquid Level
No
Sensing Mode (General)
Diffuse
Flex Relief
No
Feature: Small Object Detection
No
Housing Style
Round
Sensing End Segment 2
Ferrule
Max Temp ( °C)
70
Beam Exit
In-line
Quantity Included
1
Integrated Lens
No

Measured Max Distance (mm)

192

Max Range: DF-G3 (mm)

>1m - <=3m

Fiber Sensing End Size

4.0 mm

Feature: Chemical Resistant

Fiber Sheathing Material (Jacket)

Stainless Steel Monocoil

Termination

Terminated

Tariff Fiber Meters (fbm)

Fiber Optic Type

Plastic

Sensing End Segment 1

Thread

Minimum Repeat Bending Endurance

1000

Sensing End Material (Specific)

Stainless Steel

Core Diameter (mm)

Application: Vacuum Feed Through

None

Max Distance: DF-G2 (mm)

312

Max Distance: DF-G3 (mm)

1495

Fiber Sensing End Size - Mounting Area

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PBT46TSL5-VL on Powermatic Associates is $158.00. Order now.

About the product

Banner Engineering PBT46TSL5-VL is a fiber optic sensor designed for diffuse-reflective system applications, featuring a flex strain relief and bifurcated fiber for in-line sensing. It operates effectively at an ambient air temperature up to +70°C. This sensor is part of the Plastic fiber (Vantage Line) series, characterized by a 1mm fiber core diameter. It has a cylindrical (threaded) end tip made of stainless steel, while the fiber is constructed from plastic, and the sheath is made of polyethylene (PE). The total length of the sensor is 6ft / 2m, facilitating versatile installation options.

PBT46TSL5-VL Related Documents

PBT4 VANTAGE LINE SERIES TERMINATED S.S SHEATHED-1630954974650.pdf PBT4 VANTAGE LINE SERIES TERMINATED S.S SHEATHED-1630954974656.stp
