731-635 WAGO Industrial Automation Components

WAGO 731-635 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), and a rated impulse voltage of 6kV across these categories. The rated current is 12A. For UL standards, it has a rated voltage of 300V for Use Group B and D, with respective currents of 15A and 10A, and under UL 1977, it has a rated voltage of 600V and a current of 15A. CSA approvals mirror the UL ratings for voltage and current. This connector features 5 connection points, supports a single connection type with one level, and utilizes CAGE CLAMP technology. It accommodates solid and fine-stranded conductors ranging from 0.08 to 2.5mm2 (28 to 12 AWG), with specific capacities for ferruled conductors. The pole number is 5, with a pin spacing of 7.62mm, and dimensions of 38.76mm in width, 14.3mm in height, and 27.5mm in depth. It includes variable coding, anti-rotation protection, and is made from Polyamide (PA66) with a flammability class of UL94 V0. The connector is orange, with a chrome-nickel spring steel clamping spring, electrolytic copper contacts plated with tin, and operates within a temperature range of -60 to +100°C. It is RoHS compliant, packaged in boxes of 50, and manufactured in Germany with a GTIN of 4044918267953.
