PIFM46U Banner Through Beam Sensors

Product Details

• Weight
  45.3592 g
• Country Of Origin
  JP
• Functions
  Fiber optic sensor
• Product series / family name
  Fiber sensors
• Material
  Stainless steel sensing end Plastic fiber Polyethylene fiber sheath
• Sub-range name
  Plastic fiber series
• Length
  6ft / 2m
• Main function
  Fiber sensor
• Shape
  Cylindrical (smooth) end tip
• Order code / Manufacturer SKU
  39113
• Primary brand
  Banner Engineering
• Design
  through-beam system / opposed mode pair of individual fibers In-line sensing
• Diameter
  3mm (end) 1mm fiber core
• Ambient air temperature for operation
  +70 °C
• Housing Style
  Round
• Fiber Sensing End Tip
  Ferrule
• Quantity Included
  2
• Sensing Mode (Detailed)
  Reflective
• Sensing End Material (Specific)
  Stainless Steel
• Integrated Lens
  No
Max Distance: DF-G3 (mm)
No Data
Fiber Optic Type
Plastic
Fiber Length (m)
2
Application: Vacuum Feed Through
None
Max Distance: DF-G2 (mm)
No Data
Beam Exit
In-line
Max Temp ( °C)
70
Feature: Chemical Resistant
No
Fiber Sheathing Material (Jacket)
Polyethylene
Core Diameter (mm)
1
Tariff Fiber Meters (fbm)
4
Termination
Free Cut
Feature: Small Object Detection
No
Minimum Repeat Bending Endurance
10000
Measured Max Distance (mm)
No Data
Feature: Extended Range
No
Fiber Sensing End Size - Mounting Area
3.0 mm
Sensing Mode (General)
Opposed
Minimum Bend Radius (mm)
25
Sensing End Segment 1
Ferrule
Flex Relief
No
Application: Liquid Level
No
Max Distance: DF-G1 (mm)
No Data
Termination Type
Plastic Fiber Sensors
Fiber Sensing End Size
3.0 mm
Retractile
No
