Q12AB6FF30 W/30 Banner Electronic Components

Q12AB6FF30 W/30 on Powermatic Associates
Banner

Part#:Q12AB6FF30 W/30

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

WORLD-BEAM Q12 Series: Fixed-Field, Range: 30mm Cutoff; Input: 10-30V dc, Output: LO (Light Operate) Bipolar; 1 NPN; 1 PNP, 9 m (30 ft) Cable

Product Details

  • Primary Housing Material
    Thermoplastic
  • Quick Disconnect Type
    No QD
  • Delay at Power-up (ms)
    120
  • Opposed Mode Emitter/Receiver
    N/A
  • Cable Length (m)
    9
  • Max Sensing Distance (mm)
    30
  • Repeatability (µs)
    175
  • Barrel Diameter (mm)
    N/A
  • Sensing Mode (Detailed)
    Background Suppression (Fixed)
  • Connection
    Cable
  • Special Feature: Intrinsically Safe
    No
  • Indicator
    LEDs
  • Power
    DC
  • Special Feature: Remote Teach
    No
  • Lens Material
    Polycarbonate
  • Feature: Audible
    No
  • Sensing Beam
    Visible Red LED
  • Min Op. Temp. (°C)
    -20
  • Max Op. Temp. (°C)
    55
  • IP Rating
    IP67
  • Input/Output
    Discrete
  • Outputs
    Bipolar (NPN & PNP)
  • Sensing Beam Wavelength
    640
  • Feature: Timing (Hold/Delay)
    No
  • Housing Style
    Rectangular
  • Power Supply/Supply Voltage
    10-30 V dc
  • Number of Pins
    3
  • DeviceNet
    No
  • Sensing Mode (General)
    Proximity
  • Operation
    Light Operate
  • Special Feature: Water Detection
    No
  • Adjustments
    N/A
  • Small Visible Spot
    LED
  • Output response time (ms)
    0.85 ON/OFF
  • Max Op. Relative Humidity [%]
    95% @ 50°C
  • Feature: Hazardous Area
    No
  • Feature: Chemical Resistant
    No
  • Feature: Encapsulated
    No
  • IO Link
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
