Q13C2.0 Banner Ultrasonic Sensors

Q13C2.0 on Powermatic Associates
Banner

Part#:Q13C2.0

Alt. Part#:59424

Manufacturer:Banner

Category:Ultrasonic Sensors

Product Lifecycle:Active

Product description

Q45UR Remote Sensor Head: Flat Pak; Range: 50-250 mm; Input: depends on the controller; Output: depends on the controller; 2 m (6.5 ft) Cable

Product Details

  • Weight
    108.86208 g
  • Country Of Origin
    US
  • Primary brand
    Banner Engineering
  • Sub-range name
    Q45UR series
  • Degree of protection
    IP67 NEMA 6P
  • Emission frequency
    400kHz
  • Product series / family name
    U-GAGE series
  • Sensing distance
    50...250mm
  • Main function
    Head
  • Functions
    Remote transducer head green LED (power ON) yellow LED (output state) red LED (signal) TEACH mode
  • Shape
    Rectangular
  • Ambient air temperature for operation
    -25...+70 °C
  • Design
    time-of-flight system
  • Protection functions
    Overload Short-circuit
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Material
    thermoplastic polyester housing
  • Order code / Manufacturer SKU
    59424
  • Device Type
    Remote Sensor
  • Power Supply
    15-24 V dc
  • Min Operating Temperature (°C)
    -25
  • Feature: Timing (Hold/Delay)
    No
  • RS-422
    No
  • Housing Style
    Rectangular
  • NEMA Rating
    NEMA 4
  • PROFINET
    No
  • SSI
    No
  • Sensing Mode (General)
    Proximity
  • Minimum Sensing Distance (mm)
    50
  • Application: Ultrasonic
    Yes
  • Power
    DC
  • Quick Disconnect Type
    No QD
  • IO Link
    No
  • RS-232
    No
  • Wireless
    No
  • Max Measurement Range
    >100 mm - <=500 mm
  • Cable Length (m)
    2
  • IP Rating
    IP65
  • Number of Pins
    4
  • PC Configurable
    No
  • Primary Housing Material
    Thermoplastic Polyester
  • Ultrasonic Frequency (kHz)
    400
  • Common Ethernet Protocol
    No
  • Sensing Mode (Detailed)
    Time of Flight
  • Connection
    Flying Leads
  • Max Operating Temperature (°C)
    70
  • RS-485
    No
  • 1-wire Serial Interface
    No
  • Max Sensing Distance (mm)
    250
  • Sensing Beam
    Ultrasonic
  • Max Op. Relative Humidity Non-Condensing (%)
    85
  • Profibus
    No
  • Feature: Clear Object Detection
    Yes
  • Feature: Chemical Resistant
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q13C2.0 on Powermatic Associates is $190.00. Order now.

About the product

Banner Engineering Q13C2.0 is a control unit designed for remote transducer head applications, operating within an ambient air temperature range of -25 to +70°C. It features a time-of-flight system with TEACH mode, housed in a plastic barrel model. This unit is part of the Q45UR series and comes pre-wired with a 6.5ft / 2m cable that terminates with bare end flying leads. It boasts a rectangular shape and is constructed from thermoplastic polyester, ensuring durability. The Q13C2.0 operates at a frequency of 400kHz and offers a sensing distance between 50 to 250mm. It is equipped with protection functions against overload and short-circuit, and it is rated with a degree of protection of IP65 NEMA 4, indicating its capability to withstand dust and water ingress.
