Q25SP6FF100QP Banner Proximity Sensors
Part#:Q25SP6FF100QP
Alt. Part#:85732
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
EZ-BEAM Q25 Series: Fixed Field; Range: 100 mm; Input: 10-30 V dc; Output: Complementary PNP; 150 mm (6 in) 4-pin M12 PVC Pigtail QD
Product Details
- Weight 159.210792 g
- Country Of Origin US
- Sensing Mode (Detailed) Background Suppression (Fixed)
- Connection Pigtail QD
- NEMA Rating NEMA 6P
- Feature: Encapsulated Yes
- Sensing Mode (General) Proximity
- Special Feature: Remote Teach No
- Adjustments N/A
- Feature: Health/ Marginal Signal Output Yes
- Sensing Beam Infrared LED
- Housing Style Rectangular
- Input/Output Discrete
- Power DC
- Primary Housing Material Thermoplastic
- Outputs PNP
- Power Supply/Supply Voltage 10-30 V dc
- Max Sensing Distance (mm) 100
- Quick Disconnect Type M12 (Euro)
- Min Op. Temp. (°C) -40
- Output response time (ms) 3
- Operation Light/Dark Operate
- Max Op. Temp. (°C) 70
- Special Feature: Intrinsically Safe No
- Special Feature: Water Detection No
- Delay at Power-up (ms) 100
- Repeatability (µs) 750
- Number of Pins 4
- IP Rating IP69
- Max Op. Relative Humidity [%] 90% @ 50°C
- Barrel Diameter (mm) 18
- Indicator LEDs
- Opposed Mode Emitter/Receiver N/A
- Lens Material Acrylic
- Feature: Hazardous Area No
- Feature: Timing (Hold/Delay) No
- Feature: Audible No
- Feature: Ecolab Certified Yes
- Feature: Chemical Resistant Yes
- IO Link No
- DeviceNet No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q25SP6FF100QP on Powermatic Associates is $239.00. Order now.
About the product
Banner Engineering Q25SP6FF100QP is a fixed-field photo-electric sensor designed with a background suppression system. It features an M18 threaded mount for installation and operates within an ambient air temperature range of -40 to +70°C. This sensor is part of the Q25 DC series and offers a pre-wired 6" / 150mm pigtail terminated with a 4-pin Euro-style M12 connector for connectivity. It boasts an IP69K NEMA 6P degree of protection, ensuring durability in harsh environments. The sensor operates on a supply voltage of 10Vdc-30Vdc, with nominal values of 12Vdc / 24Vdc. Its rectangular shape is constructed from a thermoplastic housing with an acrylic lens. The Q25SP6FF100QP has a sensing distance of 100mm and utilizes infrared light with a wavelength of 880 nm. It supports both Light-ON and Dark-ON operating modes and includes 1 x digital output (PNP transistor; complementary NO/NC) with a response time of 3ms / 0.003 s.
