QMT42VN6FF500Q Banner Optical Sensors
Part#:QMT42VN6FF500Q
Alt. Part#:49228
Manufacturer:Banner
Category:Optical Sensors
Product Lifecycle:Active
Product description
QMT42 Series: Fixed Field; Range: 500 mm; Input: 10-30 V dc; Output: SPDT (Complementary) NPN; 4-pin M12 Integral QD
Product Details
- Weight 145.14944 g
- Country Of Origin CN
- Wavelength 880 nm
- Design background suppression system
- Response time 1ms / 0.001 s
- Connection type Pre-equipped with 4-pin Euro-style M12 connector
- Shape Rectangular
- Degree of protection IP67 NEMA 6
- Light Color Infrared (IR)
- Operating mode Light-ON Dark-ON
- Ambient air temperature for operation -20...+55 °C
- Order code / Manufacturer SKU 49228
- Sensing distance 500mm
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Product series / family name Q series
- Digital outputs 1 x digital output (NPN transistor)
- Main function Sensor (Photo-electric)
- Primary brand Banner Engineering
- Functions Fixed-field photo-electric sensor green LED (power ON) amber LED (light sensed)
- Material Die-cast Zinc alloy housing Acrylic lns.
- Sub-range name QMT42
- Compliant with standard(s) cURus CE
- Sensing Beam Infrared LED
- Quick Disconnect Type M12 (Euro)
- Delay at Power-up (ms) 100
- Housing Style Rectangular
- Operation Light/Dark Operate
- Lens Material Acrylic
- Barrel Diameter (mm) N/A
- Sensing Mode (General) Proximity
- Power Supply/Supply Voltage 10-30 V dc
- Special Feature: Water Detection No
- Adjustments N/A
- Power DC
- Connection Integral QD
- Sensing Beam Wavelength 880
- Feature: Encapsulated No
- Sensing Mode (Detailed) Background Suppression (Fixed)
- Min Op. Temp. (°C) -20
- Repeatability (µs) 250
- Feature: Timing (Hold/Delay) No
- DeviceNet No
- Input/Output Discrete
- Max Op. Temp. (°C) 55
- IP Rating IP67
- Indicator LEDs
- Primary Housing Material Zinc Alloy Die-Cast
- Special Feature: Remote Teach No
- Number of Pins 4
- Feature: Hazardous Area No
- Max Sensing Distance (mm) 500
- Output response time (ms) 1
- NEMA Rating NEMA 6
- Feature: Chemical Resistant No
- Outputs NPN
- Special Feature: Intrinsically Safe No
- Max Op. Relative Humidity [%] 90% @ 50°C
- Feature: Audible No
- Opposed Mode Emitter/Receiver N/A
- IO Link No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QMT42VN6FF500Q on Powermatic Associates is $266.00. Order now.
About the product
Banner Engineering QMT42VN6FF500Q is a fixed-field photo-electric sensor designed with a background suppression system. It operates within an ambient air temperature range of -20 to +55°C and is housed in a die-cast zinc alloy with an acrylic lens, ensuring durability. This sensor is pre-equipped with a 4-pin Euro-style M12 connector for easy integration and boasts a degree of protection rated at IP67 NEMA 6, making it suitable for challenging environments. It requires a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. The QMT42 series sensor features a rectangular shape and offers a sensing distance of 500mm. It utilizes infrared light with a wavelength of 880 nm and can operate in both Light-ON and Dark-ON modes. The sensor provides one digital output (NPN transistor; complementary NO/NC) and has a rapid response time of 1ms / 0.001 s.
