QS30LDQ Banner Proximity Sensors
Part#:QS30LDQ
Alt. Part#:70231
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
WORLD-BEAM QS30 Series: Laser Diffuse (Class 1); Range: 400 mm; Input: 10-30 V dc; Output: Bipolar: 1 NPN; 1 PNP; 5-pin M12 Integral QD
Product Details
- Weight 81.64656 g
- Country Of Origin US
- Sub-range name QS30 Diffuse-mode Laser sensors series
- Design diffuse mode
- Shape Rectangular
- Degree of protection IP67 NEMA 6
- Primary brand Banner Engineering
- Wavelength 650 nm
- Product series / family name WORLD-BEAM series
- Functions Class 1 Laser photo-electric sensor green LED (power ON) yellow LED (output state) TEACH mode
- Connection type Pre-equipped with 5-pin Euro-style M12 connector
- Operating mode Light-ON Dark-ON
- Ambient air temperature for operation -10...+50 °C
- Light Color Visible red
- Thread size M30
- Response time 0.5ms / 0.0005 s
- Material thermoplastic housing Acrylic lns.
- Main function Sensor (Photo-electric)
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Sensing distance 400mm
- Mounting mode Threaded mount
- Compliant with standard(s) cULus CE
- Digital outputs 1 x digital output (PNP/NPN transistor)
- Order code / Manufacturer SKU 70231
- Small Visible Spot Laser
- Special Feature: Water Detection No
- Barrel Diameter (mm) 30
- DeviceNet No
- Primary Housing Material Thermoplastic
- Outputs Bipolar (NPN & PNP)
- Power DC
- Connection Integral QD
- Repeatability (µs) 70
- Indicator LEDs
- Feature: Audible No
- Sensing Mode (General) Proximity
- Output response time (ms) 0.5
- Sensing Beam Wavelength 650
- Feature: Encapsulated No
- Housing Style Rectangular w/M30 Mount
- Power Supply/Supply Voltage 10-30 V dc
- Special Feature: Remote Teach Yes
- Lens Material Acrylic
- Input/Output Discrete
- Operation Light/Dark Operate
- Number of Pins 5
- Feature: Chemical Resistant No
- Laser Classification Class 1
- Min Op. Temp. (°C) -10
- Delay at Power-up (ms) 1000
- Adjustments Teach Button
- Sensing Beam Visible Red Laser
- Max Sensing Distance (mm) 400
- Special Feature: Intrinsically Safe No
- NEMA Rating NEMA 6
- Sensing Mode (Detailed) Diffuse
- Quick Disconnect Type M12 (Euro)
- Max Op. Relative Humidity [%] 95% @ 50°C
- Opposed Mode Emitter/Receiver N/A
- IO Link No
- Max Op. Temp. (°C) 50
- IP Rating IP67
- Feature: Hazardous Area No
- Feature: Timing (Hold/Delay) Yes
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QS30LDQ on Powermatic Associates is $218.00. Order now.
About the product
Banner Engineering QS30LDQ is a Class 1 laser photo-electric sensor designed for a variety of applications. It features a diffuse mode with TEACH mode functionality and is equipped with a 5-pin Euro-style M12 connector for easy connection. This sensor is part of the QS30 Diffuse-mode Laser sensors series and is designed for mounting via an M30 threaded mount. It operates within an ambient air temperature range of -10 to +50 °C and offers a degree of protection rated at IP67 NEMA 6, making it suitable for challenging environments. The QS30LDQ operates on a supply voltage of 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. Its rectangular shape is constructed from a thermoplastic housing with an acrylic lens. The sensing distance is up to 400mm, and it emits a visible red light with a wavelength of 650 nm. It supports both Light-ON and Dark-ON operating modes and includes 1 x digital output (PNP/NPN transistor) with a rapid response time of 0.5ms / 0.0005 s.
