S18DLHGT Banner Signal Beacons
Part#:S18DLHGT
Alt. Part#:87920
Manufacturer:Banner
Category:Signal Beacons
Product Lifecycle:Active
Product description
S18 EZ-LIGHT Daylight Visible High Intensity 18 mm 1-Color; Voltage: 9-30 V dc; Environmental Rating: IP67; Color: Green; Input: PNP; 4-screw Terminal Wiring
Product Details
- Weight 63.50288 g
- Country Of Origin CN
- Feature: Hazardous Area No
- Wireless No
- Pro-Editor Compatible (Discrete) No
- Modbus RTU No
- IO Link No
- Multi-Color Device Single Color On
- Indication Intensity High Brightness & Daylight Visible
- Feature: Audible No
- Feature: Washdown Rated Yes
- Feature: Chemical Resistant No
- Primary Window Material Polycarbonate Clear
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Min Op. Temperature (°C) -40
- Primary Housing Color Black
- Max Op. Temperature (°C) 60
- Environmental Rating IP67; IP69
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 34.6
- Max Input Response Time (ms) 1
- Input Type Bimodal (PNP/NPN)
- Supply Voltage 9-30 V dc
- Max Current Color (mA) 60
- Number of Input Pins/Conductors 4
- Color Technology Standard LED
- Animation Option 1 Solid On
- Connection Terminal
- Color 1 - Wavelength/Color Temp/Coordinates 530 nm
- Product Size (mm) 18
- Lumens Color 1 20.0
- Color Option 1 Green
- Power Source DC
- Cable Length (m) 0.15
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Mounting Thread M18 x 1.0
- Housing Style Barrel Mount - Flat Window
- Primary Housing Material Polycarbonate
- Power DC
- Number of Colors / Segments 1
- Indication Yes
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of S18DLHGT on Powermatic Associates is $61.00. Order now.
About the product
Banner Engineering S18DLHGT, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color green LED illumination. This high-intensity LED pilot light indicator features a clear Polycarbonate (PC) window and base, with a black housing. It has an 18mm indicator diameter and utilizes a screw-clamp terminal connection for installation. The S18DLHGT operates on a supply voltage of 9Vdc-30Vdc (12Vdc-24Vdc nominal) and is designed for flush mounting in an 18mm hole with an M18 thread. It can operate in ambient air temperatures ranging from -40°C to +60°C. This part is protected to IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13 standards, ensuring durability in various environments. The shape is characterized by a round protruding window and a threaded cylindrical barrel. It has a current consumption of 60mA and includes 1 x digital input (9-30Vdc; PNP) for color control.
