T30R-1515-KDQ Banner Safety Light Curtains
Part#:T30R-1515-KDQ
Alt. Part#:808907
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
T30R R-GAGE Series Radar Sensor; Range 15 m; Input: 10-30 V dc; Output: 1 PNP/NPN with IO-Link Communication; 1 PNP/NPN; 5-pin M12 Integral QD
Product Details
- Weight 90.7184 g
- Country Of Origin US
- Power DC
- Sensing Beam Radar
- PFM Output Yes
- Sensing Mode (Detailed) Time of Flight
- Operating Frequency 122 GHz
- Sensing Mode (General) Proximity
- Max Measurement Range >5 m - <=20 m
- Device Type Sensor
- Max Sensing Distance (mm) 15000
- Output Saturation Voltage PNP Outputs < 3 V at 50 mA
- Minimum Response Time (ms) 6
- Power/Current Consumption (exclusive of load) 100 mA max @ 24 V dc
- Profibus No
- Indicator LED(s)
- Power Supply 10-30 V dc
- Max Discrete (Switched) Output (mA) 50
- Remote Teach and Laser Control Input Impedence 55 kΩ
- Feature: Chemical Resistant No
- Wireless No
- Primary Housing Material PBT
- Delay at Power-up (ms) 300
- Output Protection Protected against short circuit
- Feature: Timing (Hold/Delay) Yes
- IO Link Yes
- Cert: European Yes
- Quick Disconnect Type M12 (Euro)
- Output Saturation Voltage NPN Outputs < 3 V at 50 mA
- Min Operating Temperature (°C) -40
- Feature: Remote Teach Yes
- RS-422 No
- Mechanical Shock MIL-STD-202G, Meth. 213B, conditions H&I (Shock: 75G with unit operation: 100G for non-operation).
- Barrel Diameter (mm) 30
- Feature: Clear Object Detection Yes
- Cert: US Yes
- Housing Style Barrel
- Minimum Sensing Distance (mm) 150
- IP Rating IP67
- Minimum Window Size (mm) 20
- RS-232 No
- SSI No
- PC Configurable Yes
- Connection Integral QD
- Number of Pins 5
- Max Operating Temperature (°C) 65
- Supply Protection Circuitry Protected against reverse polarity and transient overvoltages
- 1-wire Serial Interface No
- Input/Output Discrete
- Vibration MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
- Max Op. Relative Humidity Non-Condensing (%) 95 at 50°C
- Discrete Output Hysteresis (mm) Manually settable from 50 to 15000 mm
- PROFINET No
- RS-485 No
- Radar Beam Pattern (H x V °) 15 x 15
- Adjustments Software; Push Button; Remote Teach
- Discrete (Switched) Outputs 2 NPN/PNP Configurable
- Max Off-state Leakage Current (µA) NPN: < 40 at 30 V dc; PNP: < 10 at 30 V dc
- Common Ethernet Protocol No
- Cert: Australia/New Zealand Yes
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of T30R-1515-KDQ on Powermatic Associates is $646.00. Order now.
About the product
Banner Engineering T30R-1515-KDQ is a radar sensor belonging to the T30R series, designed with a time-of-flight system and approved for telecom use in the US, Europe, UK, Australia, and New Zealand. This retro-reflective radar sensor features a P.B.T. housing and is pre-equipped with a 5-pin Euro-style M12 connector. It operates on a supply voltage of 10Vdc-30Vdc, with nominal values of 12Vdc and 24Vdc. The sensor can function within an ambient air temperature range of -40 to +65°C and is protected by an IP67 degree of protection, making it suitable for harsh environments. Its M30 cylindrical threaded/barrel shape facilitates easy installation. The T30R-1515-KDQ offers two digital outputs (PNP/NPN transistor), supports a sensing distance of 0.15 to 15m, and includes protection functions against reverse polarity and short-circuit. The thread size for this sensor is M30.
