TTR457BMSB4T-2.0FL-CTR Banner Safety Light Curtains
Part#:TTR457BMSB4T-2.0FL-CTR
Alt. Part#:810317
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
TTR Series 4 Beam Sensor Array 18.0 in Between Frame; Beam Spacing: 93.1 mm; Range: 120 mm; Output: Bimodal; Input: 18-30 V dc; 2.0 m (6.5 ft) Flying Leads
Product Details
- Weight 322.05032 g
- Country Of Origin MX
- Sensing Mode (Detailed) Diffuse
- Number of Pins 4
- Indicator Indicator LEDs
- Connection Cable
- Output response time (ms) 1
- Slot Depth/Array Length (mm) 451
- Housing Style Sensing Array Bar
- Slot Overall Depth (mm) 19
- Max Op. Temperature (°C) 55
- Primary Housing Material Black Anodized Aluminum
- Cable Length (m) 2
- Power DC
- Outputs Bimodal
- Lens Material Polycarbonate
- Delay at Power-up (ms) 1500
- IP Rating IP50
- Max Sensing Range (mm) 120
- Quick Disconnect Type No QD
- Special Feature: Remote Teach No
- End Cap Type T: T-Slot Mounting
- Power Supply/Supply Voltage 18-30 V dc
- NEMA Rating N/A
- Adjustments N/A
- Min Op. Temperature (°C) -10
- Number of Beams 4
- Max Op. Relative Humidity (%) 95% @ 55°C
- Distance to First Beam [mm] 88.85
- Beam to Beam Spacing [mm] 93.1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TTR457BMSB4T-2.0FL-CTR on Powermatic Associates is $177.00. Order now.
About the product
Banner Engineering TTR457BMSB4T-2.0FL-CTR is a sensor array designed with a diffuse mode featuring 4 beams. This part is pre-wired with a 2m cable that ends with bare flying leads, facilitating easy integration into various systems. It has a rectangular shape with dimensions including a 457mm array length and a beam spacing/pitch of 93.1mm. The sensor operates within a supply voltage range of 18Vdc to 30Vdc, with a nominal voltage of 24Vdc, and can function in ambient air temperatures ranging from -10 to +70°C. It offers a degree of protection rated at IP50, making it suitable for environments where dust protection is necessary. The sensor provides one digital output (PNP/NPN transistor) and has a sensing distance of 120mm. It utilizes infrared (IR) light with a wavelength of 940 nm for detection.
