314C386G02 Eaton Industrial Automation Components

314C386G02 on Powermatic Associates
Eaton

Part#:314C386G02

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

314C386G02 Eaton - Eaton molded case circuit breaker accessory handle mechanism, Slide plate mechanism, Rotary lever handle, G02, 100 A, EH-, F-, HF-, J-, K-, AQB-, NQB-, PF-Frame, Series C

Product Details

  • Height
    3.8 inches
  • Length
    7.6 inches
  • Weight
    1.6 pounds
  • Amperage
    100 amperes
  • Type
    Slide Plate Mechanism

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
