Powermatic Associates Logo

AE56NN0A Eaton Industrial Automation Components

AE56NN0A on Powermatic Associates
Eaton

Part#:AE56NN0A

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

AE56NN0A Eaton - Eaton Freedom Series IEC Starter

Product Details

  • Type:
    Open
  • Poles:
    3
  • Shipping Height:
    13.00 In.
  • Volts:
    120 V
  • Series:
    Freedom
  • Shipping Width:
    10.00 In.
  • Shipping Length:
    15.00 In.
  • Amps:
    140 A
  • Shipping Weight:
    21.60 lbs.
  • Amperage
    140 amperes
  • Type
    Starter
  • Coil Voltage
    110/120 volts
  • Height
    11.35 inches
  • Frequency
    50-60 hertz
  • Frame
    N-frame
  • Width
    8.7 inches
  • Weight
    20 pounds
  • Number of Phases
    3
  • Length
    5.94 inches
  • Mounting Type
    Horizontal

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
