ARDA20 Eaton Industrial Automation Components

Name: ARDA20
Brand: Eaton

Part#:ARDA20

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

ARDA20 Eaton - AR/ARD Relay Four-Pole Top Deck Adder, 600 Vdc max. voltage rating, Four-pole, 2NO contact configuration

Product Details

Height
1 inch
Number of Poles
4
Voltage
600 volts
Contact Configuration
2NO
Weight
.1 pounds
Length
1 inch

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
