C306DG3B Eaton Industrial Automation Components

C306DG3B on Powermatic Associates
Eaton

Part#:C306DG3B

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

C306DG3B Eaton - Eaton definite purpose starter, NEMA 1, Enclosed contactors, 32A, NEMA size 00 or 0, Three-pole

Product Details

  • Shipping Weight:
    4.45 lbs.
  • Approval:
    UL
  • Mounting:
    Contactor/DIN Rail
  • Trip Class:
    Class 10
  • Shipping Width:
    8.00 In.
  • Terminal Type:
    Load Lug
  • Reset Type:
    Automatic/Manual
  • Shipping Length:
    12.00 In.
  • IEC Size:
    A to F
  • UPC:
    782114162835
  • Motor FLA:
    32 Ampere
  • Shipping Height:
    8.00 In.
  • Type:
    Adjustable Trip Class
  • NEMA Size:
    00
  • Series:
    Freedom, C306
  • Contact Rating:
    600 VAC 5 Ampere (NC)
  • Poles:
    3
  • Enclosure:
    NEMA 1
  • Ambient Temperature:
    Compensated
  • Auxiliary Contact:
    1NO-1NC
  • Amperage
    32 amperes
  • Size
    NEMA 0, NEMA 00
  • Type
    Enclosed Contactors
  • Height
    4.12 inches
  • Weight
    .8 pounds
  • Length
    1.77 inches

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
