Part#:D2PA7

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

D2PA7 Eaton - D2 Series Socket, Used with D2PR4, D2PF4 Relays, Module size B, 300V nominal voltage, 10A nominal current, DIN rail/panel mount, Screw clamping wire connection, QTY: 10, IP20 enclosure

Product Details

  • Series:
    D2
  • Mounting:
    DIN Rail/Panel
  • UPC:
    786685107318
  • Approval:
    UL
  • Used On:
    D2PR4/D2PF4 Series General Purpose Relay
  • Terminal Type:
    Clamp
  • Contact Rating:
    300 V at 10 Ampere
  • Shipping Weight:
    0.10 lbs.
  • Shipping Height:
    2.00 In.
  • Shipping Length:
    4.00 In.
  • Shipping Width:
    2.00 In.
  • Type
    General-purpose Relay
  • Length
    2.4 inches
  • Height
    1.18 inches
  • Mounting Type
    DIN Rail, Screw
  • IP Rating
    IP20
  • Weight
    .11 pounds

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
