ECC03C1H4A-P7 Eaton Industrial Automation Components

ECC03C1H4A-P7 on Powermatic Associates
Eaton

Part#:ECC03C1H4A-P7

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

ECC03C1H4A-P7 Eaton - Eaton C30CN mechanically held lighting contactor, START/STOP pushbutton, 30 A, 277 V/60 Hz, 30 A, NEMA 1, Painted steel, Four-pole, Electrically held, C30CN Series, Non-combination electrically and mechanically held

Product Details

  • Weight
    13 pounds
  • Enclosure Material
    Painted Steel
  • Number of Poles
    4
  • Coil Voltage
    277 volts
  • Height
    14.75 inches
  • Type
    Non-combination Electrically And Mechanically Held
  • Length
    9.75 inches
  • Amperage
    30 amperes

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
