NZMH2-A40-SVE Eaton Industrial Automation Components

NZMH2-A40-SVE on Powermatic Associates
Eaton

Part#:NZMH2-A40-SVE

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

NZMH2-A40-SVE Eaton - Eaton Series NZM complete molded case circuit breaker, NZM2-frame, NZMH2, Adj. thermal, Adj. magnetic trip, Three-pole, 40A, 750 Vdc, Dist. circuit protection, Rocker lever, motor drive, 32-40A, 320-400A delayed, 32-40A, IEC/EN 60947-2

Product Details

  • Maximum AC Voltage Rating:
    690
  • Shipping Length:
    11.00 In.
  • Terminal Type:
    Front Screw
  • Voltage Rating:
    690 VAC
  • Number of Poles:
    3
  • Shipping Height:
    6.00 In.
  • Frame Type:
    NZM2
  • Current Rating:
    32 A
  • Interrupting Rating:
    85 to 150 kA
  • UPC:
    4015081128631
  • Type:
    Thermal Magnetic
  • Size:
    105 Millimeter Width x 149 Millimeter Depth x 184 Millimeter Height
  • Shipping Weight:
    6.25
  • Shipping Width:
    8.00 In.
  • Maximum DC Voltage Rating:
    750
  • Weight
    5 pounds
  • Length
    4.05 inches
  • Circuit Breaker Type
    NZMH2
  • Amperage
    40 amperes
  • Connection Type
    Front Screw
  • Frame
    NZM2
  • Trip Type
    Adjustable Magnetic, Adjustable Thermal
  • Height
    7.24 inches
  • Class
    Distribution Circuit Protection
  • Voltage
    690 volts, 750 volts

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

NZMH2-A40-SVE Related Documents

DataSheet.pdfSpecificationTechnical.pdfCatalog.pdf
