RD316T32W Eaton Industrial Automation Components

RD316T32W on Powermatic Associates
Eaton

Part#:RD316T32W

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

RD316T32W Eaton - Eaton Series C electronic molded case circuit breaker, R-frame, RD, Complete breaker, Digitrip 310 RMS, Electronic LSI trip type, Three-pole, 1600A, 600 Vac, 65 kAIC at 480 Vac, 50 kAIC at 600 Vac, Without terminals

Product Details

  • UPC:
    786679547021
  • Shipping Width:
    21.00 In.
  • Volts:
    480/600 VAC
  • Size:
    15.5 Inch Width x 9.75 Inch Depth x 16 Inch Height
  • Shipping Height:
    22.00 In.
  • Poles:
    3
  • Interrupting Rating:
    125 Kiloamp at 240 Volt AC
  • Frame:
    RD
  • Series:
    0
  • Shipping Weight:
    99.00
  • Type:
    Electronic RMS 310 Digitrip LSI
  • Shipping Length:
    20.00 In.
  • Amps:
    1600 A
  • Terminal Type:
    Aluminum Line and Load
  • Approval:
    UL 489
  • Maximum AC Voltage:
    600 V
  • Amperage
    1600 amperes
  • Trip Type
    Electronic LSI
  • Frame
    R
  • Voltage
    600 volts
  • Height
    15.5 inches
  • Type
    New Design 310
  • Length
    9.75 inches
  • Weight
    102 pounds
  • Terminal Type
    Without Terminals
  • Interrupt Rating
    50 kiloamps
  • Width
    15.5 inches

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
